How to create a Kubernetes cluster with Terraform and AWS-EKS

Aécio Pires
Cloud Architect
É autor em livros sobre Zabbix, Puppet, Jenkins e Kubernetes. Contribui com projetos open source e pratica diariamente a cultura DevOps, utilizando ferramentas que permitem gerenciar a infraestrutura como código.
More about the author

Introduction

In this post we will go through the best practices on how to create a Kubernetes cluster with Terraform and AWS-EKS, also known as k8s (understand the reason here), using Terraform and the EKS service (Elastic Kubernetes Service) from AWS. If you don't know what Kubernetes is, check out the Uncomplicating Kubernetes material.

If you don't know what Terraform or EKS is, visit the following pages for more information:

http://blog.aeciopires.com/conhecendo-o-terraform

https://bit.ly/36iy82t

https://aws.amazon.com/eks.

As a way of giving back to the free software community, Sensedia maintains a repository on GitHub, called open-tools, where some scripts and tools that we use in the day-to-day operation of our services are published. We believe that it can help other people. Some of the Terraform commands and code that we will see in this tutorial are also published there.



Prerequisites

In this tutorial, a Kubernetes cluster will be created using EKS 1.17.x. See the new features of this version in the following links:

https://docs.aws.amazon.com/eks/latest/userguide/kubernetes-versions.html

https://kubernetes.io/blog/2019/12/09/kubernetes-1-17-release-announcement/

https://github.com/kubernetes/kubernetes/blob/master/CHANGELOG/CHANGELOG-1.17.md

Attention: In each version of Kubernetes and EKS there can be significant changes in the API (Application Programming Interface), tag and other configurations that can affect the compatibility of applications, manifests, scalability, and load balancers. So, it is very important to read the release notes and test the new version in a different environment from the production one in order to anticipate potential problems and avoid downtime.

To perform the steps in this tutorial you need to use some GNU / Linux distribution, as the commands have not been tested on MS Windows or MacOS.

You must have an AWS account and have the AdministratorAccess and PowerUserAccess policies directly associated with your account or associated with a role (group of policies) that you can use. These policies contain all necessary permissions to manage AWS resources.

You must have aws-cli version 1.16.x or higher installed. You must also configure your AWS API access credentials. Install by following the steps in this tutorial:

https://github.com/Sensedia/open-tools/blob/master/tutorials/install_awscli.md

You must have installed kubectl version 1.18.x or higher. If you don't have it installed, follow the steps in this tutorial:

https://github.com/Sensedia/open-tools/blob/master/tutorials/install_kubectl.md

Terraform version 0.12.x must be installed. Install by following the steps in this tutorial:

https://github.com/Sensedia/open-tools/blob/master/tutorials/install_terraform_0-12.md

In this tutorial, a VPC (Virtual Private Cloud) network will be created for use in the Kubernetes cluster and an AWS-S3 bucket and a table in the AWS-DynamoDB service will also be created to store the terraform state (information on the infrastructure status to be created by Terraform).

Understanding the code

Download the source code with the following commands:

cd ~

git clone git@github.com:Sensedia/open-tools.git

cd open-tools/terraform/eks

The networking-eks directory contains the necessary code to create the network infrastructure required to create the EKS cluster.

The name of each file is very intuitive and the code inside each one describes the functionality or resources to be created by Terraform. Example: The vpc.tf file contains instructions for managing the AWS VPC resource and subnets. The policies.tf file creates the necessary policies in the AWS-IAM service.

The testing.tfvars file stands out, as it contains the values of some important parameters that can be customized according to your need or preference. The outputs.tf file contains the code snippet that will display some information about the resources managed by Terraform. This information will be used to customize the mycluster-eks/testing.tfvars file.

The README.md file contains instructions and commands to be executed to create the network infrastructure.

The mycluster-eks directory contains the necessary code to create the EKS cluster.

The name of each file is also intuitive and the code inside each one describes the functionality or resources to be created by Terraform. Example: The file eks.tf contains the instructions for managing the cluster.

The files testing.tfvars and backend.tf also stand out, including the values of some important parameters that can be customized according to your needs.

The README.md file contains the instructions and commands to be executed to create the cluster.

Before executing the commands in the following section, open each file and try to understand what each one does. Consult the Terraform and AWS documentation to better understand what each feature is and their use.

Creating VPC, Bucket S3 and table in DynamoDB

In the open-tools/terraform/eks/networking-eks/testing.tfvars file we can access the region parameter, which indicates that the infrastructure will be created in the Virginia region (us-east-1), using the default profile (which is the same name in the ~/.aws/credentials file and which must contain the registered access key and secret key to access the AWS API).

If it doesn’t exist, create an asymmetric public-private key pair with the following command:

sudo ssh-keygen -t rsa -b 2048 -v -f /home/aws-testing.pem

Do not enter a password when creating the key pair, just press ENTER. The public key will be created in the following path: /home/aws-testing.pem.pub and will be registered on AWS under the name aws-testing. This public key will be associated with the EC2 instances during the cluster creation and you will be able to access via SSH in the future using the private key that is in /home/aws-testing.pem.

This information was registered in the file open-tools/terraform/eks/networking-eks/testing.tfvars in the parameters aws_public_key_path and aws_key_name.

Another important information to be customized in this same file is the address_allowed parameter, which contains the public IP address and netmask that can access the network on which the cluster will be created. By default, external access is blocked.

The name of the S3 bucket that will store the terraform state is being defined in the bucket_name parameter. The buckets name on AWS is global and there cannot be another bucket with the same name, even in different accounts. You are likely to encounter an error while running Terraform, notifying that the bucket already exists and will not be created. The solution is to define another name. This information will be used later to customize the configuration of the code that will create the cluster.

The table name in DynamoDB that will be used in conjunction with bucket S3 is used to prevent more than one person from changing the terraform state simultaneously, it is defined in the parameter dynamodb_table_name. This information will also be used later to customize the configuration of the code that will create the cluster.

Create the network infrastructure (VPC, subnets, security group, route table, NAT Gateway, Internet Gateway), policies, bucket, and table in DynamoDB with the following commands:

cd ~/open-tools/terraform/eks/networking-eks

terraform init

terraform validate

terraform workspace new testing

terraform workspace list

terraform workspace select testing

terraform plan -var-file testing.tfvars

terraform apply -var-file testing.tfvars

The creation of the network infrastructure can take 5 minutes or more.

View the infrastructure information created with the following commands:

terraform output

The following information will be used in the next section to configure some parameters in the file open-tools/terraform/eks/mycluster-eks/testing.tfvars

bucket_id

key_name

security_group

subnet_private1

subnet_public1

vpc1

Creating the EKS cluster

Edit the open-tools/terraform/eks/mycluster-eks/backend.tf file. Based on the information used in the previous section, change the following parameters:

bucket: enter the bucket name created previously. Example: “my-terraform-remote-state-01“;

dynamodb_table: enter the name of the table created in DynamoDB. Example: “my-terraform-state-lock-dynamo”;

region: enter the name of the AWS region used to create the cluster, it must be the same where the network infrastructure was created. Example: “us-east-1“;

profile: enter the name of the AWS profile with the API access credentials configured in the ~ /.aws/credentials file. It must be the same one used to create the network infrastructure. Example: “default“.

Edit the open-tools/terraform/eks/mycluster-eks/testing.tfvars file. Based on the information used in the previous section, change the following parameters:

profile: enter the name of the AWS profile with the API access credentials configured in the ~ /.aws/credentials file. It must be the same one used to create the network infrastructure. Example: “default“.

region: enter the name of the AWS region used to create the cluster, it must be the same in which the network infrastructure was created. Example: “us-east-1“;

address_allowed: the public IP address and netmask that can access the network where the cluster will be created. Example: “201.82.34.213/32”.

subnets: must contain the list with the IDs of subnet_private1 and subnet_public_1, shown at the end of the previous section. Example: [“subnet-06dd40e8124e67325”, “subnet-098580d73a131193c”];

vpc_id: must contain the vpc1 ID shown at the end of the previous section. Example: “vpc-068004d30dd97a13b”;

cluster_name: contains the cluster name. The name entered here must be the same at the end of the tags “k8s.io/cluster-autoscaler/mycluster-eks-testing” and “kubernetes.io/cluster/mycluster-eks-testing”, otherwise it will not be possible to enable cluster autoscaling. Example: “mycluster-eks-testing”;

cluster_version: contains the EKS version to be used in the cluster. Example: “1.17”;

override_instance_types: list with EC2 instance types to be used in the cluster. Example: [“t3.micro”, “t3a.micro”];

on_demand_percentage_above_base_capacity: percentage of on-demand instances to be used in the cluster. The remaining percentage will be of spot instances (cheaper, but ephemeral). Example: 50;

asg_min_size: minimum number of instances in the cluster. Example: 2;

asg_max_size: maximum number of instances in the cluster. Example: 20;

asg_desired_capacity: desired number of instances in the cluster. Example: 2;

root_volume_size: GB size of the disk to be used in each instance. Example: 20;

aws_key_name: name of the public key registered in the previous section to be used by the EC2 instances of the cluster. Example: “aws-testing”;

worker_additional_security_group_ids: list containing the security group ID created in the previous section that will be associated with the cluster. Example: [“sg-0bc21eaa5b3a26146”];

Get your AWS account ID with the following command:

aws sts get-caller-identity –query Account –output text –profile PROFILE_NAME_AWS

Where:

PROFILE_NAME_AWS: is the name of the AWS profile defined in the file configuration ~/.aws/credentials

Edit again the file open-tools/terraform/eks/mycluster-eks/testing.tfvars.

And change all occurrences of ID 255686512659 by your account ID. Also change the instance of role adsoft by the name registered in your account (if any) and change the instance of the user aeciopires by your AWS username. This is very important because the users and roles informed in the map_roles and map_users parameters will be the only admins in the EKS cluster.

Finally, create the EKS cluster with the following commands:

cd ~/open-tools/terraform/eks/mycluster-eks

terraform init

terraform validate

terraform workspace new testing

terraform workspace list

terraform workspace select testing

terraform plan -var-file testing.tfvars

terraform apply -var-file testing.tfvars

Note: The cluster creation may take 15 minutes or more.

View the information for the created cluster with the following commands:

terraform output

terraform show


Accessing the EKS cluster

Run the following command to access the cluster.

aws eks –region REGION_NAME update-kubeconfig –name CLUSTER_NAME –profile PROFILE_NAME_AWS

Where:

REGION_NAME: is the name of the region where the cluster was created.

CLUSTER_NAME: is the name of the cluster.

PROFILE_NAME_AWS: is the name of the AWS profile defined in the file configuration ~/.aws/credentials.

Example:

aws eks –region us-east-1 update-kubeconfig –name mycluster –profile default

To test access, check the pods status with the following command.

kubectl get pods –all-namespaces



Troubleshooting EKS

Information on troubleshooting EKS is available at the following links:

https://docs.aws.amazon.com/eks/latest/userguide/troubleshooting.html

https://docs.aws.amazon.com/eks/latest/userguide/troubleshooting_iam.html

https://aws.amazon.com/pt/premiumsupport/knowledge-center/eks-api-server-unauthorized-error

https://aws.amazon.com/premiumsupport/knowledge-center, section Amazon Elastic Container Service for Kubernetes (Amazon EKS)



Viewing the Price

The information about the price of using EKS, depends on the AWS region where the cluster is created, the type of EC2 instance used in the nodes workers, whether or not it is using spot instances, on-demand, if it is using reserved instances, the size and type of disk used in each worker nodes, whether or not it is using a VPC and NAT Gateway shared with other services, data transfer between the external networks involved, and whether or not it is using any Load AWS Balancer to allow external access to applications, the Load Balancer price also varies according to the type, which can be: classic (ELB), application (ALB) or network (NLB). In addition, AWS charges a fee of $ 0.10 per hour for each EKS cluster.

Get more information on AWS-EKS service pricing at:

https://aws.amazon.com/eks/pricing

https://aws.amazon.com/pt/ec2/pricing/on-demand

https://aws.amazon.com/eks/faqs

To help you get a price estimate, AWS provides a price calculator: https://calculator.aws.

See an example of the monthly and annual cost of infrastructure used in this tutorial in the Virginia region (us-east-1):

https://calculator.aws/#/estimate?id=de2c57ee696545b1fc9c6248533652724e208e5c



Documentation

The complete documentation of the resources used in this tutorial are available at the following links. Use this information to deepen your daily learning.

Terraform: https://www.terraform.io/docs

Provider AWS: https://www.terraform.io/docs/providers/aws

Terraform module for EKS: https://registry.terraform.io/modules/terraform-aws-modules/eks/aws/13.0.0

AWS-VPC: https://docs.aws.amazon.com/vpc/latest/userguide

AWS-S3: https://docs.aws.amazon.com/AmazonS3/latest/gsg

AWS-DynamoDB: https://docs.aws.amazon.com/amazondynamodb/latest/developerguide

AWS-EKS: https://docs.aws.amazon.com/eks/latest/userguide



Removing EKS cluster

Run the following commands to remove the EKS cluster:

cd ~/open-tools/terraform/eks/mycluster-eks

terraform workspace select testing

terraform destroy -var-file testing.tfvars

Removing the cluster can take 5 minutes or more.

Removing VPC and S3 buckets

Run the following commands to remove the network infrastructure created:

cd ~/open-tools/terraform/eks/networking-eks

terraform workspace select testing

terraform destroy -var-file testing.tfvars

Removing the network infrastructure can take 5 minutes or more.

If at the end of the resource’s removal, you see the following error, access the AWS web console and the URL: https://s3.console.aws.amazon.com/s3/. Locate the bucket name and check the checkbox to the left of the name. Then click on the empty button. Follow the instructions to empty the bucket.

Error: error deleting S3 Bucket …

BucketNotEmpty: The bucket you tried to delete is not empty. You must delete all versions in the bucket.

After that, edit the file open-tools/terraform/eks/networkin-eks/bucket.tf and change the parameters:

Before:

  versioning {

 enabled = true

   }

   lifecycle {

   prevent_destroy = true

  }

After:

 force_destroy = true

  versioning {

 enabled = false

  }

  lifecycle {

  prevent_destroy = false

  }

Again, run the following commands to remove the bucket:

terraform destroy -var-file testing.tfvars

This is necessary because the bucket stores the terraform state and, in a normal situation in the production environment, the bucket is not expected to be removed to avoid losing track of changes in the environment using Terraform.

Final considerations

In this tutorial we have learned how to create a kubernetes cluster from scratch using Terraform to manage the entire network infrastructure and the AWS-EKS service.

In the next tutorials we will present the use of other technologies involving EKS to perform the monitoring of metrics, deployment, and application observability.

References


https://kubernetes.io


https://bit.ly/3p9xVXZ


https://www.terraform.io


https://docs.aws.amazon.com/eks/latest/userguide/what-is-eks.html


https://github.com/badtuxx/DescomplicandoKubernetes


http://blog.aeciopires.com/conhecendo-o-terraform


https://bit.ly/36iy82t


https://docs.aws.amazon.com/eks/latest/userguide/kubernetes-versions.html


https://kubernetes.io/blog/2019/12/09/kubernetes-1-17-release-announcement/


https://github.com/kubernetes/kubernetes/blob/master/CHANGELOG/CHANGELOG-1.17.md


https://github.com/Sensedia/open-tools


https://aws.amazon.com/eks


https://aws.amazon.com/vpc


https://aws.amazon.com/s3


https://aws.amazon.com/pt/dynamodb


http://blog.aeciopires.com/primeiros-passos-com-docker


https://docs.aws.amazon.com/eks/latest/userguide/troubleshooting.html


https://docs.aws.amazon.com/eks/latest/userguide/troubleshooting_iam.html


https://amzn.to/356ge3m


https://aws.amazon.com/premiumsupport/knowledge-center


https://aws.amazon.com/eks/pricing


https://aws.amazon.com/pt/ec2/pricing/on-demand


https://aws.amazon.com/eks/faqs


https://calculator.aws
